Operating Frequency 750 kHz & 1.2 MHz Dual Frequency
Horizontal Center Beam Width 0.95° / 0.6°
Horizontal Opening Angle 140° Vertical Opening Angle 20°
Maximum Detection Range 120m I 50m Range Resolution 2.5 mm
Blind Zone 0.3m Maximum Operating Depth 300m / 1.5km
Refresh Rate (Range Dependent) Max. 40 Hz Number of Beams 768
Maximum Operating Speed 6 kn Input Voltage 18 ~ 50VDC
Communication Interface 4-wire 1 OOM Ethernet
External Connector 1 waterproof connector for transmitting signal and power signal Dimensions 300m Pressure-resistant Type: 120（士1) X 60（士 1) X 125（士 1) mm
1500m Pressure-resistant
Type: 126（士1) X 64（土1) X 130（士3) mm
Housing Material Aluminum Alloy (300m Type), Titanium Alloy (1.5km Type) Mounting Clamp Mount
